Products which have revised specifications, or changed and up-dated in some way from original stock items
CT4089
Fluid / Fuel Retriever - 1.5L
1.5 litre Fuel and Fluid Extractor
For AdBlue / Antifreeze / Brake Fluid / Diesel / Oil / Water.
Also for transmission of fluid / gear oil and engine oil / not ATF.
Suitable for fluid suction and supply during vehicle service.
Clear body for observing fluid content.
Features cap to avoid dripping.
Capacity : 1.5 litre.
CT4642
Fluid Extractor and Refill Kit - 8L
8L Pneumatic Auto Transmission Fluid Extractor and Refill Kit
with 13 Adaptor Set for Audi / Ford / Mercedes / VW.
Extract / transfer and dispense fluid quickly and cleanly
With Pre-set Safety valve for automatic shut-off.
Pressure gauge to read and control pressure.
2 way control valve for dispensing more safely.
13 one touch adaptors for automotive fluid transfer.
Screw valve to switch from extractor to dispenser.
High flow control valve to extract fluid more efficiently.
CT4950
Oil Funnel / Adaptor Set - 24pc
24 piece Engine Oil Filler Set with Rotation Handle
Allows for fast oil filling without spillage.
Great for many late model vehicles with internal baffles.
2 litre funnel fits adaptor for wide application range.
Colour coded plastic adaptors for oil filler access.
Special angle extension with swivel feature for hard to reach places.
Contains 19 specific adaptors for leakage-free connection.
CT0423
Oil Changing Machine - 12V
12V Oil Exchange and Flushing Machine with Adaptor Set
For removing and exchanging automatic transmission oil.
Also for cleaning / flushing oil cooler and oil lines.
Pump Output : 70W
Oil Pressure Gauge Diameter : 70mm
Oil Pressure Display Range : 0 - 150psi / 0 - 10bar
Fresh and Used Oil Tank Capacity : 25 litre
Red and Black Hose : 2.5M x 12.5mm Diameter
All hoses with quick couplings / plug and socket
Max. Hose Pressure : 300psi / 20 bar
CT1044
Oil Extractor - 24L
24 Litre Pneumatic Oil Extractor
Degree of Vacuum : 0 - -0.08mpa
Working Pressure : 8 - 10bar
Working Oil Temperature : 40 - 60 degrees C
Suction Speed -
0.8L/min - Hose diameter : 3.5mm
1.0L/min - Hose diameter : 4.5mm
1.6L/min - Hose diameter : 6.5mm
Designed to extract waste oil and fluids.
CT4864
Clutch Alignment Tool Set
11pc Clutch Alignment and Adjustment Tool Set
Suitable for a wide range of vehicles and some light commercial vehicles.
Screw action provides fast adjustment for required hub diameter.
8 interchangeable spigot adaptors aid close alignment.
Adaptors : 12 | 14 | 15 | 16 | 17 | 18 | 19 | 20mm diameter.
Expanding mandrels : 15 - 19mm | 20 - 26.6mm | 23 - 36mm diameter.
CT5858
Micro Puller 19 - 45mm
Fast Fit Micro Puller 19 - 45mm
Supplied with thrust shaft extension
Capacity : 1 ton
Reach : 73mm
Puller Reach : 19 - 73mm / Min-Max
Puller Spread : 19- 45mm / Min-Max
Designed for the fast and safe removal of small bearings.
Also alternators / generators / domestic appliances / power tools and pumps.
Spring loaded and drop-forged legs are secured around the bearing or gear
by a screw collar to prevent slipping and subsequent damage or injury.
CT3577
Inner Tie Rod Service Kit
Inner Tie Rod Installer / Remover Tool Set - 1/2in.Dr
Contains 12 SAE and Metric crowfoot adaptors
Sizes : 1-13/16 | 1-? | 1/5/16 | 1-3/8 | 1-7/16 | 1-1/2in.
29mm | 32.5mm | 33.6mm | 38.4mm | 40mm | 42mm
For inner tie rods that are inaccessible to adjust with a normal spanner.
The long socket slips over the tie rod end allowing the crowfoot adaptor
to engage with the fastener for easy removal and installation.
The inner tie rod can be removed and installed without removing the rack.
CT0538
Shock Absorber Tool Set - 43pc
43pc Turnbuckle Set for Shock Absorbers
Unique and comprehensive set of tools
for servicing spring or strut shock absorbers.
Suitable for a wide variety of vehicles
in conjunction with spring compressors.
Chrome Vanadium sockets and
Strut Nuts with 22mm hex drive.
Specialist bits with 10mm hex drive
Go-Thru Ratchet : 19 | 22mm.
CT4759
Brake Fluid Bleed Wrench Set - 6pc
6pc Brake Bleed Wrench Set
Sizes : 7 | 8 | 9 | 10 | 11 | 12mm - 12 point
Combined Wrench / Socket and Nipple Connector.
Ideal for bleeding brake and hydraulic clutch systems without removing the wheels.
1.2M silicon hose with check valve for safety operating.
For universal bleeder nipples.
CT2367
Brake Fluid Bleed Kit - 2pc
2pc Pneumatic Brake Extractor / Refill Kit
Kit contains a vacuum fluid extractor, bleeding hose
and automatic refill bottle with New safety design.
Automatic shut off when the tank is full.
Working pressure : 70 -170psi
Air inlet : 1/4in.
Tank Capacity : 2.0L
Bottle Capacity : 1.0L
Air consumption : 5 cfm
CT3942
Brake Piston Wind Back Tool - LH / RH
5pc Brake Caliper Piston Rewind Kit - 3/8in.Dr
With powerful internal spring
T-Bar : 150mm | Main Body : 110mm plus Reaction Plate.
Magnetic 2 pin adaptor with 5mm diameter pins - for any standard rewind adaptor.
Adjustable 2 pin adaptor with 3mm diameter pins
from 25mm to 34mm pin centres - for electronic park brakes.
Adjustable 3 pin adaptor with 3mm diameter pins
from 17mm to 30mm pin centres - for common brake Caliper applications.
CT4773
Brake Line Jig Set - 2pc
2pc Brake Line Jig Set
Clamp both new and old lines parallel
to each other to make exact copies.
A brake line can consist of many angles /
bends that should be correct for the new line to fit.
For steel / cooper and plastic coated brake lines
with 3/16in. or 1/4in.| 4.75mm to 6.3mm diameters.
CT3385
Bearing Extractor Set
16pc Bearing Extractor Set
Puller and Slide-Hammer
Screw Adaptors : M6 x 1.0 / M8 x 1.25 / M10 x 1.5
Collets : 8 - 11mm / 12 - 17mm / 18 - 23mm / 24 - 29mm
30 - 34mm / 34 - 38mm / 39 - 43mm / 44 - 48mm / 49 - 53mm / 54 - 58mm
Ideal for dismantling bearings installed in a blind hole.
CT4767
Wheel Locking Nut Key Set - 21pc Vauxhall / Opel
21pc Wheel Locking Nut Key Set
For removing Vauxhall / Opel locking wheel nuts on -
Agila | Astra F/G/H | Calibra | Corsa B/C/D |
Meriva | Omega B | Signum | Speedster |
Tigra A/B | Vectra B/C | Zafira A/B.
Vauxhall Wheel Lock Nut Keys equivalent to
OEM Z16512-181 to Z16512-200
With 17mm Alloy Wheel Nut Socket.
CT4768
Wheel Locking Nut Key Set - 10pc Land Rover
10pc Land Rover Wheel Locking Nut Key Set
Master Set of Tamper-proof Sockets
for removing the locking wheel nuts on Land Rover vehicles.
Hex Drive - Identified with : A | B | C | D | E | F | G | H | I | J.
Use with a 27mm Spanner or Socket
NOT for use with Impact Tools.
CT5263
Portable Soda Blasting Gun
Soda Blasting Gun
Capacity : 1000ml
Operating Pressure : 6.3 - 8.2 bar
Air consumption : 57L/min
Air Inlet : 1/4in.bsp
Suitable for automotive use in removing
paint / mould / carbon / grease and rust.
Use with environmentally friendly soda blasting agents.
Particularly useful where less aggressive cleaning is required
